A-Data Legend 800





LEGEND 800 PCIe Gen4 x4 M. 2 2280 Solid State Drive

● PCIe Gen4 x4

● Max. read/write speed: 3,500/2,800MB/s

● Capacity: Up to 2000GB

● Supports NVMe 1.4

● Supports latest Intel and AMD platforms



Evolve Your Creativity

LEGEND 800 supports the latest PCIe Gen4 x4 interface, which meets the NVMe 1.4 standard. It offers excellent read and write performance, and support for the latest Intel and AMD platforms. Whether on a desktop or notebook PC, progress you creativity.





Unlock Inspiration

LEGEND 800 delivers sequential read and write speed of 3,500/2,800MB per second, which is up to 2 times faster than a standard PCIe Gen3 SSD and 6 times faster than a SATA SSD. It is backward compatible with PCIe 3.0 and made for creating, whether 3D graphic of video!





More than Ample 2000GB Capacity

With 3D-stacked flash memory, the LEGEND 800 provides you with capacities of up to 2000GB. What's more, it comes with various protection and correction technologies, and high TBW (Total Bytes Written) for durability and reliability.





Imagine the Possibilities

Creativity can't wait! The LEGEND 800 is equipped with SLC caching and HMB technology (Host Memory Buffer) for seamless productivity.







Keeping Things Cool

The LEGEND 800's black heat sink design with bronzing trimming and sandblasted surfaces look cool and keep things cool. Through a cutting-edge surface treatment, it dissipates heat incredibly effectively reducing temperature.







Create Without Worry

LDPC (Low Density Parity check Code) and AES 256-bit encryption ensure data accuracy and file security.





Specifications:

Capacity

500GB / 1000GB / 2000GB

Form factor

M. 2 2280

NAND Flash

3D NAND

Dimensions (L x W x H)

80 x 22 x 2.65mm / 3.15 x 0.87 x 0.1inch (with heat sink)

80 x 22 x 2.15mm / 3.15 x 0.87 x 0.09inch (without heat sink)

Weight

With heat sink：7g / 0.26oz

Without heat sink：6.3g / 0.22oz

Interface

PCIe Gen4 x4

Sequential Read (Max)

Up to 3,500MB/s*

Sequential Write (Max)

Up to 2,800MB/s*

Operating temperature

0°C - 70°C

Storage temperature

-40°C-85°C

Shock resistance

1500G/0.5ms

MTBF

2,000, 000 hours

Terabytes Written (TBW)

1200TB**



Продукт известен още и като LEGEND 840 2 TB M 2 ALEG 800 2000 GCS, LEGEND8402TBM2ALEG8002000GCS, LEGEND 840 2TB M.2 (ALEG 800 2000GCS), LEGEND8402TBM2ALEG-800-2000GCS, LEGEND 840 2TB M.2 (ALEG-800-2000 GCS)
